jQuery实现可拖拽3D万花筒旋转特效 112 2024-02-06

这是一个使用了CSS3立体效果的强大特效,本特效使用jQuery跟CSS3 transform来实现在用户鼠标按下拖动时,环形图片墙可以跟随鼠标进行3D旋转动画。

进去后可以上下左右的拖动图片。

本示例中使用到了CSS3的transform-style 属性,该规定如何在 3D 空间中呈现被嵌套的元素。

默认值: flat

继承性: no

版本: CSS3

JavaScript 语法: object.style.transformStyle="preserve-3d"

有2个属性值可选择:

flat 子元素将不保留其 3D 位置。

preserve-3d 子元素将保留其 3D 位置。

示例代码如下:

<!DOCTYPE html>
<html lang="zh">
<head>
<meta charset="UTF-8">
<meta http-equiv="X-UA-Compatible" content="IE=edge,chrome=1">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>jQuery可拖拽3D万花筒旋转特效 - 何问起</title><base target="_blank" />
<style type="text/css">
 *{margin:0;padding: 0;}
 .hovertree{
 width: 120px;
 height: 180px;
 margin: 150px auto 0;
 position: relative;
 /*transform 旋转元素*/
 transform-style:preserve-3d;
 transform:perspective(800px) rotateX(-10deg) rotateY(0deg);
 }
 body{background-color: #66677c;}
 .hovertree img{
 position: absolute;
 width: 100%;
 height: 100%;
 border-radius: 5px;
 box-shadow: 0px 0px 10px #fff;
 /*倒影的设置*/
 -webkit-box-reflect:below 10px -webkit-linear-gradient(top,rgba(0,0,0,0) 50%,rgba(0,0,0,.5) 100%);
 }
 .hovertree p{
 width: 1200px;
 height: 1200px;
 background: -webkit-radial-gradient(center center,600px 600px,rgba(255,255,255,.5),rgba(0,0,0,0));
 position: absolute;
 top:100%;left:50%;
 margin-top: -600px;
 margin-left: -600px;
 border-radius:600px;
 transform:rotateX(90deg);
 }
 .hewenqi{position:absolute;z-index:99;}
 a{color:blue;}
</style>
</head>
<body>
<div class="hovertree">
 <img src="http://hovertree.com/texiao/css/14/hovertreepic/01.jpg"/>
 <img src="http://hovertree.com/texiao/css/14/hovertreepic/02.jpg" />
 <img src="http://cms.hovertree.com/hvtimg/201511/9rour12a.jpg"/>
 <img src="http://hovertree.com/texiao/css/14/hovertreepic/04.jpg"/>
 <img src="http://hovertree.com/texiao/css/14/hovertreepic/05.jpg"/>
 <img src="http://hovertree.com/texiao/css/14/hovertreepic/06.jpg"/>
 <img src="http://hovertree.com/texiao/css/14/hovertreepic/07.jpg"/>
 <img src="http://hovertree.com/texiao/css/14/hovertreepic/08.jpg"/>
 <img src="http://hovertree.com/hvtimg/201511/6j9j6tk5.png"/>
 <img src="http://cms.hovertree.com/hvtimg/201512/wfevf6yh.jpg"/>
 <p></p>
</div>
<script src="http://down.hovertree.com/jquery/jquery-1.11.0.min.js" type="text/javascript"></script>
<script type="text/javascript">
 $(function(){
var imgL=$(".hovertree img").size();
var deg=360/imgL;
var roY=0,roX=-10;
 var xN=0,yN=0;
 var play=null;
 $(".hovertree img").each(function (i) {
 $(this).css({
 //<translateZ 定义2d旋转沿着z轴-->
 "transform":"rotateY("+i*deg+"deg) translateZ(300px)" });
 //<防止图片被拖拽-->
 $(this).attr('ondragstart','return false');
 });
 $(document).mousedown(function(ev){
 var x_=ev.clientX;
 var y_=ev.clientY;
 clearInterval(play);
 console.log('我按下了');
 $(this).bind('mousemove',function(ev){
  /*获取当前鼠标的坐标*/
  var x=ev.clientX;
  var y=ev.clientY;
  /*两次坐标之间的距离*/
  xN=x-x_;
  yN=y-y_;
  roY+=xN*0.2;
  roX-=yN*0.1;
  console.log('移动');
  //$('body').append('<div style="width:5px;height:5px;position:absolute;top:'+y+'px;left:'+x+'px;background-color:red"></div>');
  $('.hovertree').css({
   transform:'perspective(800px) rotateX('+roX+'deg) rotateY('+roY+'deg)'
  });
  /*之前的鼠标坐标*/
  x_=ev.clientX;
  y_=ev.clientY;
 });
 }).mouseup(function(){
  $(this).unbind('mousemove');
  var play=setInterval(function(){
  xN*=0.95;
  yN*=0.95
  if(Math.abs(xN)<1 && Math.abs(yN)<1){
  clearInterval(play);
  }
  roY+=xN*0.2;
  roX-=yN*0.1;
  $('.hovertree').css({
   transform:'perspective(800px) rotateX('+roX+'deg) rotateY('+roY+'deg)'
  });
  },30);
 });
});
</script>
<div style="text-align:center;margin:250px 0; font:normal 14px/24px 'MicroSoft YaHei';">
 <p class="hewenqi">来源:<a href="http://hovertree.com/">何问起</a> <a href="http://hovertree.com/h/bjag/5x3kdw0k.htm">说明</a></p>
</div>
</body>
</html>

以上就是本文的全部内容,希望本文的内容对大家的学习或者工作能带来一定的帮助,同时也希望多多支持绿夏网!
